Description

Specifications with standard inclusions:

• ATM 2850KG
• TARE 1350KG. (without options)
• PAYLOAD 1500KG
• BALL WEIGHT 120KG
• Overall length of storage area 3000mm
• Overall length of trailer 4500mm
• 15’’ Alloy wheels inc spare.
• Heavy duty RHS Hot dipped galvanised chassis 100×50 x 4mm
• Precision CNC Laser cut Zinc Anneal sheeting & Duragal framing.
• Aluminium checker plate stone guard (removable for repaint)
• Roof rack 1450mm wide, rear full roller, 8 x tie down points, mesh floor.
• Front rack, bolt on 1450mm wide – same width as roof rack.
• Front saw bench holders with tie down points.
• Side access ladder
• Base 12v Package – Dual AGM battery system, Lighting control panel, fuse protection, 5 x LED light bars two inside main compartment & three on inside of doors, voltmeter, USB charging point, Cig socket, fridge sockets.
• Anderson plug on drawbar for charging battery from tow vehicle.
• 8 leaf Rocker Roller suspension and Solid 50mm square Axles (Rated 3.5 tonne)
• Dual 10’’ electric brake hubs on both axles with 6 stud Land cruiser stud pattern
• Safety breakaway kit fitted.
• 3500kg Tow Coupling to suit 50mm ball with handbrake.
• Front side drawer, 700L X 220W X 170D
• Rear wall with 3 X shelves, 4 x storage levels in rear door.
• 2 x Massive rear drawers 1920L X 475W X 320 Deep with C channel and bearing rollers (not draw runners) 3 – point locking system for extra security with locking rods, whale tail locks that can also be padlocked – great security system when working remote or leaving your trailer on a construction site.
• Main compartment doors – 3-point locking system with locking rods, whale tail locks that can also be padlocked, great security system when working remote or leaving your trailer on a construction site.
• Front storage box, 610mm wide x 1500mm long, two side access doors, either use as a compressor box or
  fridge box or have fully open for extra storage.
• Surface finish – UV Stabilised Powder coat.

Customise – Different trades require Different setups. When designing your
trailer, we have you covered with a versatile base package that can be tailored to
your needs. Builders / plumbers / painters / electricians / Mechanics / Hydraulic
hose fitters / Farrier / Veterinarian’s – we have done them all.

• 240v Packages available – 10a Power inlet with 20a RCD / MCB combination circuit breaker, double pole
  power points fitted, test and tag (fitted to caravan and portable buildings standard by licensed electrician)
• Standalone solar packages – 3 different install packages available depending on your requirements, solar with
  1200 / 1600 / 2000w inverter kits all installed with Victron energy systems (top of the range equipment).
• Lithium Batteries – from 100 – 400ah batteries available (Revolution power marine Quality)
• Drop Saw Slides – 500mm – 600mm – 700m wide slides available.
• Trailer toolboxes – 1200 & 1400mm long toolboxes available.
• Shelving – Different configurations available.
• Fridges & Fridge slides – Available
• 270 Awnings – Available
• Travel Buddy Ovens – Available
• Hose reels, dropdown work vice – Available

Specifications subject to change. Get in touch for more information.

* Subject to finance criteria
